PAK400-101000 Temperature Controller. Type K Input.
Dual display universal digital programmable temperature controller that supports most types of thermocouple sensors.
Features: Dual LED display, settable unit for Fahrenheit (°F) and Celsius (°C). Temperature display range is -199~1800°C, accuracy: 0.3%F.S±2dgt. Auto-tuning PID adjustment to choose for different applications or environments to be controlled. Available for many TC or RTD input, precise, stable and simple for use. Many hobby and industrial uses including lighting industry, chemistry, machine, metallurgy(etc.) to control the temperature.
Notice: R: RELAY; S: SSR; N: None RNR model represents the main control is RELAY, with only 1 alarm(RELAY). SSR model represents the main control is SSR, with 2 alarms(SSR and RELAY).
Specifications: Model: TA4-RNR / TA4-SSR (Optional) Power Supply: 90-260V AC/DC 50/60Hz Consumption: ≤5VA Display Range: -199~1800°C / -326.2~3272°F Accuracy: 0.3%F.S±2dgt Sampling Cycle: ≤300ms Main Output: RELAY: Normal Open AC250V/5A DC 30A/5A COSφ=1; SSR: 24V DC ±2V/ 20mA Alarm: RELAY: RELAY: Normal Open AC250V/5A DC 30A/5A COSφ=1; SSR: 24V DC ±2V/ 30mA Thermocouple Support: TC(K,J,S,E) / RTD(Pt100) T/C Input: K: 0~1200°C; J: 0~1200°C; S: 0~1600°C; E: 0~1000°C RTD Input: Pt100: -199~600°C Withstand Voltage Strength: 1500V Rms(Between Power Terminal and the Housing) Installation Resistance: Min. 50MΩ(Between Power Terminal and the Housing) Environment Temperature: 0~50°C Storage Temperature: -10~60°C Environment Humidity: 35~85%RH Item Size: 85 * 48 * 48mm / 3.35 * 1.89 * 1.89in Item Weight: 113g / 3.98oz Package Size: 10 * 5.5 * 6.5cm / 3.94 * 2.16 * 2.56in Package Weight: 142g / 5.01oz
Package List: 1 * Temperature Controller 2 * Bracket 1 * User Manual (English)
